Анотація
Показано узагальнений розрахунок коефіцієнта магнітозчеплення для двофазного двонаправленого перетворювача з чередуванням фаз. Період перемикання такої системи був поділений на режими, основні параметри системи були проаналізовані в кожному режимі. Пульсації струму в кожній фазі можуть бути легко визначені з використанням результатів розрахунку, і вони залежать від значень шпаруватості та коефіцієнта зчеплення. Також було показано, що коефіцієнт магнітозчеплення впливає на пульсації струму в фазі, але не впливає на пульсації вихідного струму. Виходячи зі збільшення індуктивності однієї фази за рахунок магнітозв`язку, було обрано оптимальний коефіцієнт зчеплення. Експериментальний прототип двонаправленого двофазного перетворювача з чередуванням фаз підтвердив правильність методики розрахунку коефіціента магнітозчеплення. Бібл. 15, рис. 4.
Посилання
Tytelmaier K., Husev O., Veligorskyi O., Yershov R., A Review of Non-Isolated Bidirectional DC-DC Converters for Energy Storage Systems. Proc. of II International Young Scientists Forum on Applied Physics and Engineering. Kharkiv, 10-14 October 2016. Pp. 1-7.
Wong P.-L., Xu P., Yang B., Lee F.C. Performance Improvements of Interleaving VRMs with Coupling Inductors. IEEE Transactions on Power Electronics. 2001. Vol. 16. No. 4. Pp. 499-507.
Zu G., McDonald B.A., Wang K. Modeling and Analysis of Coupled Inductors in Power Converters. IEEE Transactions on Power Electronics. 2011. Vol. 26. No. 5. Pp. 1355-1363.
Shin H.-B., Park J.G., Chung S.-K., Lee H.-W., Lipo T.A. Generalised steady-state analysis of multiphase interleaved boost converter with coupled inductors. IEE Proc.-Electric Power Application. 2005. Vol. 152. No. 3. Pp. 584-594.
Yang F., Ruan X., Yang Y., Ye Z. Interleaved Critical Current Mode Boost PFC Converter with Coupled Inductor. IEEE Transaction on Power Electronics. 2011. Vol. 26. No. 9. Pp. 2404-2413.
B. Hesterman. Analysis and Modeling of Magnetic Coupling. Denver Chapter IEEE Power Electronics Society. 2007. 93 p.
Qiu Y. Coupled inductors for power supplies. EE Times-India. 2007. Vol. 1. Pp. 1-4.
K. Kroics, U. Sirmelis, V. Brazis. Design of coupled inductor for interleaved boost converter. Przeglad Elektrotechniczny. 2014. Vol. 12. Pp. 91-94.
Ayele G.T. Challenges of Multi-channel Interleaved Bidirectional Power Converters and their Digital Solutions: author`s abstract of Dr. tech. sci. diss. University of Nottinghan. Nottinghan. 2015. 73 p.
Ikriannikov A. The benefits of the coupled inductor technology. Maxim Integrated tutorial 5997. 2014. 10 p.
Yao K. High Frequency and High-Performance VRM Design for the Next Generation of Processors: author`s abstract of Dr. tech. sci. diss. Virginia Polytechnic Institute and State University. Blacksburg. 2004. 193 p.
Wong P.-L., Performance Improvement of Multi-Channel Interleaved Voltage Regulator Modules with Integrated Coupling Inductors: author`s abstract of Dr. tech. sci. diss. Virginia Polytechnic Institute and State University. Blacksburg. 2001. 224 p.
Mu M., Lee F.C., Jiao Y., Lu S. Analysis and Design of Coupled Inductor for Interleaved Multiphase Three-Level DC-DC Converter. Applied Power Electronica Conference and Exposition (APEC). Charlotte. 15-19 March 2015. Pp. 2999-3006.
Texas Instruments. SLVA477B Basic calculation of a Buck Converters Power Stage. 2015. 8 p.
Texas Instruments. AN-1197 Selecting Inductors for Buck Converter. 2013. 18 p.
