ВРАХУВАННЯ В CЛАБКОЗВ’ЯЗАНІЙ КОЛО-ПОЛЬОВІЙ МОДЕЛІ АСИНХРОННОГО ДВИГУНА ВИТІСНЕННЯ НАВЕДЕНОГО СТРУМУ В КОЛІ РОТОРА
ARTICLE_4_PDF

Ключові слова

induction motor
current displacement effect
method
weakly coupled circuit-field model асинхронний двигун
ефект витіснення струму
метод
слабкозв’язана коло-польова модель

Як цитувати

[1]
Головань, І. і Попович, О. 2025. ВРАХУВАННЯ В CЛАБКОЗВ’ЯЗАНІЙ КОЛО-ПОЛЬОВІЙ МОДЕЛІ АСИНХРОННОГО ДВИГУНА ВИТІСНЕННЯ НАВЕДЕНОГО СТРУМУ В КОЛІ РОТОРА . ТЕХНІЧНА ЕЛЕКТРОДИНАМІКА. 3 (Квіт 2025), 022. DOI:https://doi.org/10.15407/techned2025.03.022.

Анотація

Розроблено ітераційно-параметричний метод розв'язку рівнянь слабкозв'язаної коло-польової моделі асинхронного двигуна (АД), який враховує ефект витіснення струму в роторі. Метод полягає в ітераційному розв'язанні рівнянь колової та польової математичної моделі шляхом уточнення параметрів заступної схеми АД за результатами польового аналізу та в ітераційному коригуванні розрахункового електромагнітного моменту задля врахування ефекту витіснення струму, отриманого на основі еквівалентних струмів у струмопровідних частинах ротора. Запропонований підхід дає змогу підвищити достовірність результатів моделювання електромагнітних процесів у АД в пускових режимах. Проведено верифікацію методу шляхом моделювання пускових режимів роботи АД з короткозамкненим ротором та АД з масивними феромагнітними елементами магнітопроводу, що дозволило оцінити вплив врахування ефекту витіснення струму за величиною уточнюючого моменту, яким і корегується розрахунковий електромагнітний момент колової моделі. Дослідження обгрунтувало необхідність адаптації сітки кінцевих елементів задля забезпечення точності розрахунків, коли ефект витіснення струму значно впливає на результати. Бібл. 26, табл. 1, рис. 4.
